Lianli O11 Dynamic Evo Xl Case – White

 949,00

Brand: Lianli

Description

  • Full-tower chassis with two modes: Normal Mode/ Reverse Mode
  • Front and side tempered glass panels with a removable pilar for a seamless view of components and RGB lighting
  • Supports up to 3x 420mm radiators and a maximum of 11 fans
  • Offers mounting space for 7 storage drives
  • Dual-chamber layout with cable management compartment and three cable holders
  • Number of PSU supported : 1
  • Features a multi-directional power button and movable IO module
  • Optional accessories for vertical GPU or upright GPU mounting
  ... people are viewing this right now

  Share

SPECIFICATION

Category Specifications
Model O11 Dynamic EVO XL
Case Type Full-Tower (Dual Chamber)
Color White
Dimensions (H?W?D) 520 ? 285 ? 471 mm (20.5 ? 11.2 ? 18.5 in)
Material Steel frame + 4mm tempered glass (3 panels)
Weight 14.5 kg (32 lbs)
Motherboard Support E-ATX (up to 280mm), ATX, Micro-ATX, Mini-ITX
Drive Bays 6 x 2.5″ SSD, 3 x 3.5″ HDD (or 9 x 2.5″ total)
Expansion Slots 8+3 (vertical GPU support)
Front I/O 2x USB 3.2 Gen2 Type-C, 4x USB 3.0, HD Audio
Fan Support – Top: 3x140mm or 3x120mm
– Side: 3x140mm or 3x120mm
– Bottom: 3x120mm
– Rear: 1x120mm
Radiator Support – Top/Side: 420mm or 360mm
– Bottom: 360mm
– Rear: 120mm
Max GPU Length 446mm
Max CPU Cooler Height 167mm
PSU Support ATX (max 220mm length)
Special Features – Modular design (reversible panels)
– Dual chamber layout
– Vertical GPU mount included
– Improved cable management

Key Features:

  • 420mm Radiator Support?(Top/Side)
  • Enhanced Modularity?(Reversible door/panels)
  • Dual Chamber Design?(Improved thermal management)
  • Premium White Finish?(With black interior accents)

Cooling Configuration Options:

  1. Air Cooling Focused:
    • Bottom: 3x120mm intake
    • Side: 3x140mm intake
    • Top: 3x140mm exhaust
    • Rear: 1x120mm exhaust
  2. Water Cooling Focused:
    • Top: 420mm radiator
    • Side: 420mm radiator
    • Bottom: 360mm radiator

Included Accessories:

  • Vertical GPU mounting kit
  • Cable management straps
  • Magnetic dust filters
  • All necessary screws and standoffs

Compared to Standard O11 Dynamic EVO:

  • Larger Size?(Supports 420mm radiators)
  • More Drive Bays?(6x SSD vs 3x in standard)
  • Additional USB Ports?(Dual Type-C)
  • Enhanced Build Flexibility?(More radiator/fan options)
